BOD Incubator 5-65℃

BOD Incubator 5-65℃

Biochemical Oxygen Demand (BOD) incubator

A Biochemical Oxygen Demand (BOD) incubator is a specialized laboratory instrument that provides a controlled, dark, and temperature-regulated environment (typically between 5°C and 60°C, and commonly held at a steady 20°C) with heating and cooling capabilities

BOD Incubator 5-65℃

Biochemical Oxygen Demand (BOD) incubator

Primary Uses

• Biochemical Oxygen Demand (BOD) Testing: Measures the amount of dissolved oxygen microorganisms consume while breaking down organic matter in water samples over a standard 5-day period.
• Water and Wastewater Quality Monitoring: Assesses municipal and industrial wastewater, effluent discharges before environmental release, and drinking water safety
– Microbial and Fungal Culturing: Grows and maintains cultures of bacteria, yeast, and molds that require low or ambient-controlled temperatures (such as soil and water microbes).

• Pharmaceutical Stability Studies: Conducts shelf-life, drug stability, and quality control testing under tightly regulated thermal conditions.
• Food and Beverage Quality Control: Tests food samples for spoilage organism growth and microbial safety.
– Plant and Cell Tissue Culture: Provides a stable environment for agricultural research, seed germination, and biological or biochemical experiments

Components of BOD IncubatorsBOD Incubator 5-65℃:
Knowledge about the BOD incubator structure and its essential elements enables effective laboratory operation through reliable scientific output. A BOD incubator diagram with label contains these components.
Exterior Structure: The external part includes insulation layers, which function to preserve optimal interior temperature conditions.
Inner Chamber: The interior chamber of the device uses stainless steel as its material because it gives durability alongside simple cleaning capabilities.
Toughened Glass Window: The toughened glass window enables observation of samples without door opening, which avoids temperature variations.
Air Circulation Fan: Uniform temperature distribution depends on an air circulation fan, which distributes air across the chamber.
Removable Shelves or Trays: Shelves and trays provide adjustable placement areas that suit different sample sizes along with multiple sample quantities.
Temperature Sensor: The control system receives temperature feedback from the integrated temperature sensor, which monitors chamber interior temperature conditions.
Digital PID Temperature Controller: A digital PID Temperature Controller operates with precise functionality to control the heating and cooling systems at desired temperatures.
Refrigeration System: The refrigeration system depends on compressors to generate cooling that meets requirements below ambient temperatures for specific applications.
Heating Element: The heating element supplies the heat needed for maintaining chamber temperature and possible temperature increases.
Safety Thermostat: The safety thermostat functions as a protective system through its capability to stop heating element power when the temperature reaches predetermined threshold levels.
Control Panel: Through the Control Panel, users can set all operational settings, including temperature exposure duration as well as other parameters.
Door Handle with Lock and Key: The chamber becomes secure through the combination of the door handle with lock and key, which both control entry while preserving internal environmental conditions.
Caster wheels: Facilitate easy movement and positioning of the incubator within the laboratory.

BOD Incubator 5-65℃

Biochemical Oxygen Demand (BOD) incubator

Key attributes
Type Constant Temperature Incubator
temperature fluctuation ±2℃
Power. 500W;600W;800W;1000W;1200W;1400W
humidity fluctuation /
warranty 3 Years
customised support OEM, ODM
model number ICB-50BI/80BI/150BI/250BI/350BI/460BI
brand name SCITEK
material Stainless steel inner liner
weight 51;61;87;112;139;168kg
Product name Cooling Biochemical Incubator
Capacity(L) 50L;80L;150L;250L;350L;460L
Temperature Range 0 to -65 °C
Temperature Resolution 0.1℃
Temperature Fluctuation ±2℃
Power Supply 220V 50Hz
Power Consumption 500W; 600W; 800W; 1000W; 1200W; 1400W
Gross Weight (kg) 51;61;87;112;139;168kg
Controller PID controller
Display Digital LCD dispaly

BOD Incubator 5-65℃

Biochemical Oxygen Demand (BOD) incubator BOD Incubator 5-65℃
