Electric Geology Drying Ovens
Electric Geology Drying Ovens For Soil +10~200℃(300℃)
Electric geology drying ovens are used in the mining and geology sectors for drying mineral and ore samples, which is critical for moisture control, accurate analysis, and reducing transportation costs. Other uses include the drying, heating, and heat treatment of a variety of substances like geotechnical, coal, and asphalt samples, ensuring materials are suitable for downstream processes, testing, or long-term storage.
Key Uses in Geology & Mining
Electric Geology Drying Ovens
Moisture Control:
Drying removes moisture from raw ore samples, which is vital before their chemical or physical analysis to ensure accuracy.
Preparation for Analysis:
Drying is essential to prepare samples for further laboratory work, such as determining their composition or properties.
Reduced Transportation Costs:
Drying minerals and ores lightens them by removing water weight, making them more economical to transport.
Sample Stabilization:
By removing moisture, these ovens prevent issues like corrosion, clogs, or the hardening of certain materials, ensuring stability.
Other Applications
While specialized for geology, electric drying ovens share common applications with general laboratory and industrial ovens:
Drying: Removing moisture from various samples and materials.
Sterilization: Sterilizing lab equipment like glassware.
Thermal Testing: Performing tests that require consistent, dry heat.
Baking and Curing: Used for baking, heat treatment, or solidifying substances.
Aging: Performing high-temperature aging tests on materials or components.
Electric Geology Drying Ovens
Model. YPO-072 YPO-270 YPO-480 YPO-600 YPO-720 YPO-1000
Inner chamber size W×H×D(cm) 40×45×40 60×90×50 80×100×60 100×100×60 120×100×60 100×100×100
Exterior chamber size W×H×D(cm) 90×105×55 110×160×65 130×170×75 150×170×75 170×170×75 116×150×166
Temperature range. Room temperature+10~200℃(300℃)
Perform-ance.
Temp.& humi fluctuation. ±0.3℃
Temp.& humi uniformity. ±1%℃
Temperature resolution 0.1℃
Heat up time. 30min
Material. Exterior chamber material. Cold-rolled steel+Powder coating
Interior chamber material. SUS#304 Stainless steel plate
(Use SUS#201 when max.temp.is below 200℃)
Insulation. PU&fiberglass
System. Wind circulation. Cooling fan
Heating system. SUS#Stainless steel high-speed heater
Controller CAHO H961KV02 controller(Taiwan)
Other components. Cable port(dia.50mm),control status indicator,loading shelf(2pcs,position-adjustable)
Safety devices. Over-heat protection circuit breaker,overload protection,overload indicator
Power supply AC 3phase380V 60/50Hz
Customization. Non-standard or special requirements are all welcome
