Density balance (or hydrostatic balance) measures density primarily for solids and powders using buoyancy and Archimedes’ principle, while a density meter measures density primarily for liquids and gases using the oscillating U-tube method.

Density Balance (Hydrostatic Balance)

• How it works: It uses a standard analytical or precision balance equipped with a density determination kit (a beaker, a submerged basket or pan, and a temperature probe)
• Method: It weighs a solid sample twice—first suspended in the air, and a second time submerged in an auxiliary liquid of known density (like water or ethanol).
The balance software calculates the volume via water displacement and outputs the density.
• Best used for: Solid objects, granules, plastics, metals, rocks, and porous materials. Y

Density Meter

Common Applications

• Quality Control: Checking purity, homogeneity, and raw material composition in manufacturing.
• Gem and Jewelry: Distinguishing real precious metals and gemstones from f cuáles or alloys based on specific gravity.
• Plastics and Polymers: Verifying proper curing, density grading, and material consistency.
• Research and Education: Laboratory testing in chemistry, physics, and material science

Density Balance Feature:
1. High precision measurement
Adopting advanced sensor technology to ensure accurate and reliable measurement results.
High resolution, capable of detecting small density changes.
2. Multifunctionality
Suitable for various materials, including metals, plastics, ceramics, liquids, and powders.
Can measure samples of different shapes and sizes.
3. User friendly design
Equipped with a large LCD display, the readings are clear and intuitive.
Easy to operate, users can easily set and operate through buttons.
4. Automation function
Automatic calibration function ensures the accuracy of each measurement.
Automatic temperature compensation reduces the impact of environmental temperature on measurement results.
5. Durable and sturdy
Made of high-quality materials, the structure is sturdy and suitable for long-term use.
Dustproof and waterproof design, suitable for various working environments.
6. Widely used
Suitable for various occasions such as laboratories, factories, quality control departments, etc.
Plays an important role in material research, production monitoring, and quality inspection.

Product Parameters
Model BA-DS203 BA-DG203 BA-DA203 BA-DS303 BA-DG303. BA-DA303
Capacity(g) 210 310
Weighing Accuracy 0.001g 0.005g

Density Accuracy 0.001g/cm³
Test Capacity. 0.001-99.999g/cm³
Scale Size 60x152mm
Pan Size. 70x110mm

In the water
Tank Size. 139x100x78mm water tank
Operation temperature 5-35℃

Key name
Power, F, ENTER, CAL, 0
Calibration weight 200g
Material Aluminium Case
Outlook size 205x270x370mm
Packing Size 440x310x300mm
Test Object S-solid/G-gold/A-absorption
Weight 4.5kg
Density Kit Solid kit
