Biological Safety Cabinet Class BSC-IIB2-1100
Lead Time: 4-6 Weeks
Class II B2 Biological safety cabinet is biological safety isolation equipment used in biological safety laboratories or other laboratories.
Biological Safety Cabinet Class II B2, are total exhaust cabinets, widely used in toxicology laboratories and similar applications where chemical effluent is present and clean air is essential.
Biosafety Cabinet Class II Features:
Biosafety Cabinet
Biosafety Cabinet Class II Display
Biosafety Cabinet Class II Type B2 Specifications:
| Model |
BSC-IIB2-1100 |
BSC-IIB2-1400 |
BSC-IIB2-1500 |
BSC-IIB2-1800 |
| External Size (WxDxH)mm |
1050x836x2150 |
1400x836x2150 |
1500x836x2150 |
1800x836x2150 |
| Internal Size (WxDxH)mm |
950x666x600 |
1300x666x600 |
1350x666x600 |
1625x666x600 |
| Tested Opening |
Safety Height 200mm (8”) |
| Max.Opening |
400mm |
| Work Surface Height |
800mm |
| Airflow System |
100% air exhaust |
| Downflow Velocity |
0.34m/s |
| Inflow Velocity |
0.55m/s |
| Blower |
German EBM Blower |
| Filter Specification |
Two, AAF ULPA filter, 99.9995% efficiency at 0.12 μm, filter life indicator |
| Cleanliness Grade |
Class 100 (ISO14644.1 Class 5) |
| Display |
LCD touch screen |
| Alarm |
Abnormal airflow velocity, ULPA filter failure, UV lamp failure, Front window at unsafe height |
| Front Window |
Motorized, Two-layer laminated toughened glass ≥ 5mm. Anti UV. |
| LED Lamp |
30Wx2 |
36Wx2 |
36Wx2 |
36Wx2 |
| UV Lamp |
20Wx1 |
30Wx1 |
40Wx1 |
40Wx1 |
| Rated Consumption |
2060W |
2082W |
2092W |
2092W |
| Illumination |
≥800Lx |
| Sound Emission |
≤67dB(A) |
| Power Supply |
AC220V±20, 50Hz，110V,60HZ (Optional) |
| Material |
External Main body: Electro-galvanized steel with antimicrobial Powder Coating
Work surface: 304 stainless steel |
| Standard Accessories |
1.Base stand; 2.Air Velocity sensor; 3.AAF ULPA filter; 4.EBM Blower; 5.LCD touch screen; 6.LED lamp; 7.UV lamp; 8.Waterprof socket; 9.Motorized Front window; 10.Caster; 11.Exhaust Blower; 12.Exhaust duct (Φ300mm) |
| Optional Accessories |
1.Gas tap; 2.Water tap; 3.IV bar with hooks; 4.Pressure meter |
| Net Weight |
284kg |
323kg |
350kg |
430kg |
| Gross Weight |
346kg |
404kg |
435kg |
550kg |
| Shipping Size (WxDxH) mm (Main Unit) |
1210x1140x1710 |
1560x1140x1710 |
1650x1140x1710 |
1950x1140x1710 |
Shipping Size (WxDxH)mm
(Exhaust Blower) |
700x700x500 |
700x700x500 |
700x700x500 |
700x700x500 |
| Shipping Volume (m3) |
2.7 |
3.4 |
3.5 |
4.1 |
