Ph Meters

MODEL: 8601

  • Dual LCD display shows pH/°C & °F or mV/°C & °F
  • Automatic Temperature Compensation assures that all readings are corrected to compensate for the effect of temperature
  • Hold, Max/Min, Record features
  • Low battery indicator
  • Auto power off after 20 minutes
  • Manual temp. compensation by external probe
  • Calibration up to 3 points (pH 4.01, 7.00, 10.00)
  • BNC connector for pH electrodes w/ 1 meter length
  • Mini-phone jack for Temp. Compensation probe
  • Meter includes hard ABS case, battery, pH buffer solutions (4.01, 7.00, 10.00) each 30ml and manual
  • Serial format: 2400 Baud rate, 1 Stop bit, 8 Data bits, TXXX.XF, XX.XpH, TXXX.XC, XX.XmV
  • Applications include: Pools, Spas, Aquariums, Labs, Aquaculture, Sanitation plants, Car washes, Hydroponics, Water & Wastewater treatment, and Boilers/Steam generator maintenance

SPECIFICATION

  • pH range: 0.00~14.00
  • pH resolution: 0.01 pH
  • pH accuracy: 0.02 pH
  • mV range: -499~+499mV
  • mV resolution: 0.1mV (0.1~195.0) or 1mV (190~499)
  • mV accuracy: 0.2mV (0.1~195) or 2mV (190~499)
  • Optional RS232 software with CDR & PC Cable
  • Operating Temp.: 0~50°C (32~122°F), Max. 80% RH
  • Input Impedance: 1012 ohms
  • Temperature compensation: -5~80°C Accuracy: 0.3°C
  • Optional accessories:
    • pH electrode AZ86P2 – Epoxy-body w/o ATC
    • pH electrode AZ86P3 – Epoxy-body with ATC

Z8601 AT A GLANCE

  • Dual display pH/mV & temperature! Automatic temperature compensation!
  • Collect data via linking with a PC! Backlight display for use in dark areas!
